Evaluation Electronics

Panel Mount Displays (FAS 100)

with analog and frequency output

High Precision Evaluation Units – FAS 100 Series

The FAS 100 are high precision frequency meter for panel mount, with control outputs.

All versions come with a graphic display, an intuitive user interface, a scalable 4 - 20 mA output and a frequency output. K-factor and display dimension are freely settable for adapting the unit to any meter and application. The input fits to pickups with 24 V frequency output.

Optional features are a 20 point linearization, control in- and outputs for batching or limit surveillance and a built in RS485 interface.

For fast test setups in the lab and easy setup of individual parameters, the PC based control SW EasyControl for WINDOWS is available free of charge.

View specification View documents

Functions & Specifications

Technical Data: Frequency input for 24V digital signals
Analog Output: 4 to 20 mA
24 V frequency output, freely scalable
20 point linearization of the measured value
Control input and Control input
RS485 interface
Features: High accuracy
Intuitive user interface
Remote control SW free of charge

Pickups, Amplifiers, Evaluation Electronics and Additional Accessories

Accessories

Din Rail Mount Adapter (HSA)

Din Rail Mount Adapter for panel mount housings

View specification

Show details

Accessories

Protective Cover (IPS)

Protective Cover for panel mount housings

View specification

Show details

Accessories

Interface Converter (CON.USB.RS-ISO)

USB to RS485

View specification

Show details

Accessories

24 V Wall Plugin Power Supply (SN1-24)

View specification

Show details

Documents, Manuals & Software

Title	Date	Language	Download
High Precision Evaluation Units – Datasheet FAS 100	01.01.2022	English (EN)	PDF (606 KB)
High Precision Evaluation Units – Manual FAS 100/FAW 100	02.11.2022	English (EN)	PDF (2 MB)
